WIMA MKP-X2Metallized Polypropylene (PP) RFI-Capacitors Class X2.

Capacitances from 1000 pF to 10 µF.
Rated Voltage 305 VAC.
PCM 7.5 mm to 37.5 mm.

PDF-File

Special Features

  • Reliable self-healing
  • High degree of interference suppression due to good attenuation and low ESR
  • According to RoHS 2011/65/EU

Typical Applications

Class X2 RFI applications to meet EMC regulations
  • Capacitors connected to the mains between phase and neutral or phase conductors
  • General requirements, pulse peak voltage < 2.5 kV

Construction

Dielectric: Polypropylene (PP) film
Capacitor electrodes: Vacuum-deposited
Encapsulation: Solvent-resistant, flame-retardent plastic case with epoxy resin seal, UL 94 V-0
Terminations: Tinned wire
Marking: Colour: Red. Marking: Black.

Internal construction:

Construction WIMA MKP-X2 capacitors

Electrical Data

Capacitance range: 1000 pF to 10 µF
Rated voltage: 305VAC
Continuous DC voltage* (general guide): < 560V
Capacitance tolerances: ±20%, ±10%, ±5%
Operating temperature range: -55°C to +105°C
Climatic test category: 55/105/56 in accordance with IEC
Passive flammability class:
B for capacitors with V > 1750 mm3
C for capacitors with V < 1750 mm3
Insulation resistance at +20°C:
C < 0.33 µF: > 1.5 x 104 MΩ
C > 0.33 µF: > 5000 sec (MΩ x µF)
Measuring voltage: 100V/1 min.
Dissipation factors at +20°C: tanδ
at f C < 0.1 µF 0.1 µF < C < 1.0 µF C > 1.0 µF
1kHz
10kHz
100kHz
< 18 x 10-4
< 20 x 10-4
< 50 x 10-4
< 20 x 10-4
< 60 x 10-4
-
< 20 x 10-4
-
-
Test specifications: In accordance with IEC 60384-14
Maximum pulse rise time: 100 V/µsec for pulses equal to a voltage amplitude with √2 x 305VAC = 432V according to IEC 60384-14
Test voltage:
C < 1.0 µF: 2260VDC, 2sec
C > 1.0 µF: 1800VDC, 2sec
Reliability: Operational life > 300000 hours. Failure rate < 2 fit (0.5 x Ur and 40°C)
Approvals:
Country Authority Specification Symbol Approval-No.
Germany


USA/Canada
VDE


UL
IEC 60384-14/4

UL 60384-14
CAN/CSA-E60384-14
ENEC
UL
40003472


E 134915
* If safety-approved EMI suppression capacitors are operated with a DC voltage being above the specified AC voltage rating the given approvals are no longer valid (IEC 60384-14).
Furthermore the permissible pulse rise time du/dt (Fmax.) will be subject to a reduction according to
Fmax. = Fr x √2 x UAC / UDC
if the DC operating voltage UDC is higher than √2 x UAC

Mechanical Tests

Pull test on pins: 10 N in direction of pins according to IEC 60068-2-21
Vibration: 6 hours at 10...2000Hz and 0.75mm displacement amplitude or 10g in accordance with IEC 60068-2-6
Low air density: 1kPa = 10 mbar in accordance with IEC 60068-2-13
Bump test: 4000 bumps at 390 m/sec2 in accordance with IEC 60068-2-29

Packing

Available taped and reeled up to and including case size 15x26x31.5 / PCM 27.5mm.

General Data

Capacitance 305 VAC*
W H L PCM** Part number
1000 pF
1200 "
1500 "
1800 "
2200 "
2700 "
3300 "
3900 "
4700 "
5600 "
6800 "
8200 "
4
4
4
4
4
4
4
4
4
4
4
4
9
9
9
9
9
9
9
9
9
9
9
9
10
10
10
10
10
10
10
10
10
10
10
10
7.5
7.5
7.5
7.5
7.5
7.5
7.5
7.5
7.5
7.5
7.5
7.5
MKX2AW11002C00_ _ _ _
MKX2AW11202C00_ _ _ _
MKX2AW11502C00_ _ _ _
MKX2AW11802C00_ _ _ _
MKX2AW12202C00_ _ _ _
MKX2AW12702C00_ _ _ _
MKX2AW13302C00_ _ _ _
MKX2AW13902C00_ _ _ _
MKX2AW14702C00_ _ _ _
MKX2AW15602C00_ _ _ _
MKX2AW16802C00_ _ _ _
MKX2AW18202C00_ _ _ _
0.01 µF
.
0.012 "
.
0.015 "
.
0.018 "
.
0.022 "
.
0.027 "
.
0.033 "
.
0.039 "
.
0.047 "
.
.
0.056 "
.
0.068 "
.
0.082 "
.
4
5
4
5
4
5
4
5
4
5
5
5
5
5
5.7
5
5.7
6
5
6
5
6
5
6
5
9
11
9
11
9
11
9
11
9
11
10.5
11
10.5
11
12.5
11
12.5
12.5
11
12.5
11
12.5
11
12.5
11
10
13
10
13
10
13
10
13
10
13
10.3
13
10.3
13
10.3
13
10.3
13
18
13
18
13
18
13
18
7.5
10
7.5
10
7.5
10
7.5
10
7.5
10
7.5
10
7.5
10
7.5
10
7.5
10
15
10
15
10
15
10
15
MKX2AW21002C00_ _ _ _
MKX2AW21003F00_ _ _ _
MKX2AW21202C00_ _ _ _
MKX2AW21203F00_ _ _ _
MKX2AW21502C00_ _ _ _
MKX2AW21503F00_ _ _ _
MKX2AW21802C00_ _ _ _
MKX2AW21803F00_ _ _ _
MKX2AW22202C00_ _ _ _
MKX2AW22203F00_ _ _ _
MKX2AW22702E00_ _ _ _
MKX2AW22703F00_ _ _ _
MKX2AW23302E00_ _ _ _
MKX2AW23303F00_ _ _ _
MKX2AW23902F00_ _ _ _
MKX2AW23903F00_ _ _ _
MKX2AW24702F00_ _ _ _
MKX2AW24703H00_ _ _ _
MKX2AW24704B00_ _ _ _
MKX2AW25603H00_ _ _ _
MKX2AW25604B00_ _ _ _
MKX2AW26803H00_ _ _ _
MKX2AW26804B00_ _ _ _
MKX2AW28203H00_ _ _ _
MKX2AW28204B00_ _ _ _
0.1 µF
.
.
0.12 "
0.15 "
.
.
0.18 "
.
0.22 "
.
.
0.27 "
.
0.33 "
.
.
0.39 "
0.47 "
.
.
0.56 "
.
0.68 "
.
.
0.82 "
.
8
5
6
6
6
8
6
8
6
9
8
6
8
7
11
9
7
8.5
8.5
10.5
9
10.5
9
10.5
11
9
11
9
12
11
12.5
12.5
12.5
15
15
15
15
14
15
15
15
16.5
14
16
16.5
18.5
18.5
19
19
19
19
19
21
19
21
19
13
18
18
18
18
18
26.5
18
26.5
18
18
26.5
18
26.5
18
18
26.5
26.5
26.5
26.5
31.5
26.5
31.5
26.5
26.5
31.5
26.5
31.5
10
15
15
15
15
15
22.5
15
22.5
15
15
22.5
15
22.5
15
15
22.5
22.5
22.5
22.5
27.5
22.5
27.5
22.5
22.5
27.5
22.5
27.5
MKX2AW31003I00_ _ _ _
MKX2AW31004B00_ _ _ _
MKX2AW31004C00_ _ _ _
MKX2AW31204C00_ _ _ _
MKX2AW31504C00_ _ _ _
MKX2AW31504F00_ _ _ _
MKX2AW31505B00_ _ _ _
MKX2AW31804F00_ _ _ _
MKX2AW31805B00_ _ _ _.
MKX2AW32204H00_ _ _ _
MKX2AW32204F00_ _ _ _
MKX2AW32205B00_ _ _ _
MKX2AW32704F00_ _ _ _
MKX2AW32705D00_ _ _ _
MKX2AW33304M00_ _ _ _
MKX2AW33304J00_ _ _ _
MKX2AW33305D00_ _ _ _
MKX2AW33905F00_ _ _ _
MKX2AW34705F00_ _ _ _
MKX2AW34705G00_ _ _ _
MKX2AW34706A00_ _ _ _
MKX2AW35605G00_ _ _ _
MKX2AW35606A00_ _ _ _
MKX2AW36805G00_ _ _ _
MKX2AW36805I00_ _ _ _
MKX2AW36806A00_ _ _ _
MKX2AW38205I00_ _ _ _
MKX2AW38206A00_ _ _ _
1.0 µF
.
.
1.2 "
1.5 "
.
.
1.8 "
.
2.2 "
.
.
.
2.7 "
.
.
3.3 "
.
.
.
3.9 "
.
.
4.7 "
.
.
5.6 "
.
6.8 "
.
8.2 "
.
11
11
13
11
13
15
13
13
13
15
17
13
15
17
15
17
17
20
15
17
17
17
19
20
19
20
19
20
20
24
24
31
21
21
24
21
24
26
24
24
24
26
29
24
26
29
26
29
34.5
39.5
26
29
34.5
29
32
39.5
32
39.5
32
39.5
39.5
45.5
45.5
46
26.5
31.5
31.5
31.5
31.5
31.5
41.5
31.5
41.5
31.5
31.5
41.5
41.5
31.5
41.5
41.5
31.5
31.5
41.5
41.5
31.5
41.5
41.5
31.5
41.5
41.5
41.5
41.5
41.5
41.5
41.5
41.5
22.5
27.5
27.5
27.5
27.5
27.5
37.5
27.5
37.5
27.5
27.5
37.5
37.5
27.5
37.5
37.5
27.5
27.5
37.5
37.5
27.5
37.5
37.5
27.5
37.5
37.5
37.5
37.5
37.5
37.5
37.5
37.5
MKX2AW41005I00_ _ _ _
MKX2AW41006B00_ _ _ _
MKX2AW41006D00_ _ _ _
MKX2AW41206B00_ _ _ _
MKX2AW41506D00_ _ _ _
MKX2AW41506F00_ _ _ _
MKX2AW41507C00_ _ _ _
MKX2AW41806D00_ _ _ _
MKX2AW41807C00_ _ _ _
MKX2AW42206F00_ _ _ _
MKX2AW42206G00_ _ _ _
MKX2AW42207C00_ _ _ _
MKX2AW42207D00_ _ _ _
MKX2AW42706G00_ _ _ _
MKX2AW42707D00_ _ _ _
MKX2AW42707E00_ _ _ _
MKX2AW43306I00_ _ _ _
MKX2AW43306J00_ _ _ _
MKX2AW43307D00_ _ _ _
MKX2AW43307E00_ _ _ _
MKX2AW43906I00_ _ _ _
MKX2AW43907E00_ _ _ _
MKX2AW43907F00_ _ _ _
MKX2AW44706J00_ _ _ _
MKX2AW44707F00_ _ _ _
MKX2AW44707G00_ _ _ _
MKX2AW45607F00_ _ _ _
MKX2AW45607G00_ _ _ _
MKX2AW46807G00_ _ _ _
MKX2AW46807H00_ _ _ _
MKX2AW48207H00_ _ _ _
MKX2AW48207I00_ _ _ _
10 µF
.
24
31
45.5
46
41.5
41.5
37.5
37.5
MKX2AW51007H00_ _ _ _
MKX2AW51007I00_ _ _ _
* f = 50/60 Hz
** PCM = Printed circuit module = pin spacing.
Dims. in mm.

Dimensional drawing WIMA MKP-X2 capacitors
d = 0.6 Ø if PCM < 10
d = 0.8 Ø if PCM 15 - 27.5
d = 1.0 Ø if PCM = 37.5

Part number completion


Tolerance: 20 % = M
10 % = K
5 % = J
Packing: bulk = S
Pin length: 6-2 = SD

Rights reserved to amend design data without prior notification.
